Compact and Lightweight Design
Authorized with the latest barcode decoding technology and algorithm, workers can easily capture all the right barcodes on numerous labels, all with one press of the scan trigger. 2.8-inch IPS color display provides right screen to display all necessary information from looking up price and availability to replenishing inventory on the retail shop.
M52 Touch Mobile Computer Series
Long Battery Life gives you a Seamless full-time shift
The high capacity battery supports uptime of 10 hours, and 23 days standby. GS M52 has super low energy mode, achieving fast charging of 2.5 hours. With a long-lasting battery, ensuring it can last through an entire work shift without the need for frequent recharging.
Durable and Robust and More Affordable RFID Application
The capture ability and flexibility of RFID contribute much more on the efficiency and accuracy that M52R has. This small, lightweight, and durable device offers the mobile data features bring you efficiency and accuracy to everyday tasks and fits right in the warehouse, or the manufacturing floor. M52R is a cost-effective solution for businesses looking to equip their workforce with mobile devices.
Increased Productivity and Enhanced Data Collection Accuracy
With the ability to read multiple RFID tags simultaneously and at a distance, M52R significantly speed up the process of locating and identifying items, thereby increasing employee productivity. M52R mobile computers provide real-time visibility into inventory levels, helping businesses to efficiently manage stock, reduce overstocking or stockouts, and improve inventory turnover rates.
Resources
Specifications for M52 Series Touch Mobile Computer
M52 Touch Moblie Computer | M52R Touch Mobile Computer | |
Dimension | 155mm(L) x 59.6mm(W) x 18.7mm(H) | 155mm(L) x 59.6mm(W) x 33.7mm(H) |
Weight | 170g with battery | 263g with battery |
Buttons | 21-key numeric keypad, right&left scan key, power key | 21-key numeric keypad, right&left scan key, power key |
Voice and Audio | Two microphones with noise cancellation, vibrate alert, speakers | Two microphones with noise cancellation, vibrate alert, speakers |
Operating System | Android 9 | Android 9 |
CPU Model | quad core, 2. 0 GHz | quad core, 2.0 GHz |
Display | 2.8", IPS, QVGA 320*240 pixels, sunlight viewable capacitive screen | 2.8", IPS, QVGA 320*240 pixels, sunlight viewable capacitive screen |
Memory | RAM: 2GB, Flash: 16GB | RAM: 2GB, Flash: 16GB |
Primary Camera | Main camera autofocus, 8 million pixels, photoflash | Main camera autofocus, 8 million pixels, photoflash |
Battery/Charger | 2700mAh, integrated, 5V 2A Adaptor | 4600mAh, integrated, 5V 2A Adaptor |
Interface Ports | USB 2.0, Type-C, charging/data, bottom charging interface | USB 2.0, Type-C, charging/data, bottom charging interface |
Light Indicator | Red light on when scanning Green light indicates decoding succeed Red light remains on indicates low battery Charging - Red indicates charging Green indicates fully charged Green light remains on indicates missed call and unread message | Red light on when scanning Green light indicates decoding succeed Red light remains on indicates low battery Charging - Red indicates charging Green indicates fully charged Green light remains on indicates missed call and unread message |
NFC Frequency | 13.56MHz | 13.56MHz |
NFC Smart Tag | ISO 14443 A/B ISO 15693 MIFARE | ISO 14443 A/B ISO 15693 MIFARE |
NFC Reading Distance | 0-5cm | 0-5cm |
Protocol | -- | EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C |
Working Spectrum Range | -- | 902 ~ 928MHz |
RFID Power Output | -- | 18 ~ 26dBm |
Inventory Tag Peak Speed | -- | ＞50 pieces/second |
Antenna | -- | 2dBi Circular Polarization Ceramic Antenna |
RFID Reading Distance | -- | 1m to 3m |
WLAN | IEEE802.11 a/b/g/n/ac 2.4G/5G | IEEE802.11 a/b/g/n/ac 2.4G/5G |
Bluetooth | BT 5.0/BLE | BT 5.0/BLE |
Imager Sensor | 640x480 pixels | 640x480 pixels |
Field of view | 48° horizontal 34° vertical | 48° horizontal 34° vertical |
Illumination | White LED | White LED |
Aiming | LED Red | LED Red |
Symbol Decode Capability | 1D: code39, code128, code 32, codabar, code 93, UPC-A, UPC-E, EANS, EAN13, MSI, GS1-128 2D: Aztec Code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR Code, QR Code, Digimarc Postal Code: Australian Post, British Post,China Post, IMB, Japanese Post, KIX Post, Korea Post, Planet Code, Postnet, Royal Mail Code (RM4SCC) | 1D: code39, code128, code 32, codabar, code 93, UPC-A, UPC-E, EAN8, EAN13, MSI, GS1-128 2D: Aztec Code, China Han Xin Code, Data Matrix, Maxi-Code, Micro QR Code, QR Code, Digimarc Postal Code: Australian Post, British Post, China Post, IMB, Japanese Post, KIX Post, Korea Post, Planet Code, Post-net, Royal Mail Code (RM4SCC) |
Operating Temperature | -25℃ - 50℃ | -25℃ - 50℃ |
Storage Temperature | -30℃ - 70℃ | -30℃ - 70℃ |
Humidity | 5%-95% non-condensing | 5%-95% non-condensing |
Drop Spec. | Drop from 1.2m on concrete, 3 times on each side | Drop from 1.2m on concrete, 3 times on each side |
Tumble Spec. | 300 hits of 0.5m tumble | 300 hits of 0.5m tumble |
Sealing | IP65 | IP65 |
Electrostatic Discharge (ESD) | ± 8 kv contact discharge ± 15 kv air discharge | ± 8 kv contact discharge; ± 15 kv air discharge |
Certification | CCC, SRRC, FCC, CE | CCC, SRRC, FCC, CE |
Software Supported | Generalscan Keyboard Pro Generalscan SDK Demo Generalscan OTA Tools G-Service | Generalscan Keyboard Pro Generalscan SDK Demo Generalscan OTA Tools G-Service |
Decode Range | 5mil Code 39 50.0-190.0MM
10mil DataMatrix 50.0-130.0MM
13mil EAN-13 40.0-330.0MM
20mil Code 39 90.0-460.0MM
| 5mil Code 39 50.0-190.0MM
10mil DataMatrix 50.0-130.0MM
13mil EAN-13 40.0-330.0MM
20mil Code 39 90.0-460.0MM
|
Packing&Accessories | GS M52 x1, User Guide x1, Adaptor x1, USB data-transfer cable x1, protective case x1 | GS M52R x1, User Guidex1, Adaptorx1,USB data-transfer cablex1 |
